How This Site Draws Its Post Cards

Every post on this site now receives a mathematical card: the image above the article and the image shown when its link is shared. It is generated from the post itself, not selected from a stock library and not drawn by hand. The system treats a post as a compact, reproducible input to a visual program.

That property matters more than novelty. A social image may be cached, indexed, or inspected long after it was first rendered. Regenerating a card from the same committed post must produce the same pixels, while an edit to the post should be able to change the result. The implementation uses no external random state, network call, or generation service: it is a deterministic function of the authored text.

The two hashes

Let $B$ be a normalized version of the article body and $M$ a normalized version of its front matter. The generator computes the standard SHA-256 digests (NIST 2015)

Normalization converts line endings, removes HTML and Markdown punctuation, collapses whitespace, and lowercases text. This avoids changing a card merely because a writer chose an equivalent line break or emphasis marker. It does not attempt to understand meaning; it produces a stable textual source.

The subscript $s$ means shape and $c$ means color. Splitting the input is intentional. The body digest controls geometry; the title, date, status, categories, and tags control palette and framing. A prose revision can redraw the image without quietly changing its editorial treatment. Conversely, a better title or new tag can recolor the card without changing its drawing.

For a byte $b$, define $u(b) = b / 256$. This maps a digest byte to the half-open interval $[0, 1)$. The drawing family is

SHA-256 is designed to distribute arbitrary inputs evenly over its output space, so each of the five residue classes has the same size. This is a uniform hash partition, not a claim that the system understands a post’s topic. Similar essays can produce different drawings, and an unrelated edit can change every parameter. The relationship is provenance, rather than semantic illustration.

All remaining choices are derived from further digest bytes. When a method needs pseudo-random points, its generator is seeded from a fixed byte slice of $H_s$. There is therefore no hidden clock, machine state, or random seed to record.

Five drawing families

Each family fills the same 1200 by 630 pixel canvas. The available methods are deliberately different: continuous vector fields, discrete partitions, complex-plane iteration, local Boolean dynamics, and a nonlinear orbit. They share a deterministic interface, but they do not collapse into one visual style.

Trigonometric flow fields

For the flow-field family, the plane is sampled over a rectangular grid. Three digest-derived coefficients $a$, $b$, and $c$ define an angle field

The vector field is then

Streamlines follow this field numerically. The hash selects the three frequencies and a streamline density between 1.6 and 2.8. Since the field is smooth but not usually integrable to a simple potential, it produces ribbons, turning channels, and occasional saddle-like regions without a particle simulation or nondeterministic integration.

Voronoi regions and local networks

The Voronoi family samples between 18 and 40 sites in a slightly enlarged canvas rectangle. At every raster point $p$, its assigned cell is

where $q_i$ is site $i$. Coloring this nearest-site index yields a hard partition of the plane. The sites are not merely decorative: each is connected to its three nearest neighbours, producing a sparse local graph over the regions. The graph is intentionally approximate rather than a formal Delaunay triangulation; it exposes local structure while keeping the method small, fast, and reproducible.

The hash-seeded sample positions determine both the regions and the network. Consequently, two cards cannot differ only in palette while retaining the same accidental point arrangement unless their body digest is also the same.

Julia sets

The Julia family iterates a quadratic map over the complex plane:

Each pixel starts from $z_0 = x + i y$, with $(x,y)$ spanning $[-1.8, 1.8] \times [-1.0, 1.0]$. The generator chooses one of several curated constants, including values near $-0.8 + 0.156i$ and $-0.7269 + 0.1889i$, then applies a small digest-derived perturbation. Curating the base constants avoids broad regions of parameter space that are mathematically valid but visually empty at card scale.

Iteration stops when $\lvert z_n \rvert > 2$, the usual escape radius for this quadratic map. The number of iterations lies between 96 and 191. Escaped points receive a smooth escape-time value,

which removes harsh bands from the color field. Points which do not escape are masked to the dark background. This is why the Julia cards retain a strong silhouette and contrast instead of becoming uniformly bright noise.

Elementary cellular automata

The cellular family is a one-dimensional binary automaton shown through time. For a cell with left, centre, and right states $L$, $C$, and $R$, form the neighbourhood number

An eight-bit Wolfram rule supplies the next state,

The generator selects from a fixed collection of nontrivial rules such as 30, 45, 90, 110, 122, and 150. A hash-seeded sparse first row is combined with one live central cell, then evolved for 252 rows across 480 columns with periodic boundary conditions. The result is a space-time diagram: every horizontal row is a complete state, and every diagonal trace records causal propagation through the local rule.

De Jong dynamical systems

The final family uses a two-dimensional nonlinear recurrence commonly called a De Jong attractor:

The four coefficients are independently mapped into $[-2, 2)$ from the digest. Starting at $(0.1, 0.1)$, the generator discards the first 500 states as a transient and records the next 150,000. Rather than drawing each point directly, it bins the orbit into a 900 by 480 two-dimensional histogram and displays $\log(1 + h)$, where $h$ is the bin count. The logarithm makes both dense attractor cores and faint outer structure visible. Some parameter choices form a compact attractor; others disperse. That variation is an expected property of the recurrence, not a fallback failure.

Palette and frame are a second system

The shape digest never chooses a color. Instead, the first byte of $H_c$ selects one of five named palette families, and later bytes perturb its hue, saturation, and accent values. The palette is generated in HSV space. A dark, complementary background is paired with three brighter accents at fixed hue offsets. Those accents define a continuous colormap for scalar images and the line or point colors for geometric images.

The fourth byte of $H_c$ selects one of four restrained frames:

The choices are a single rule, a double rule, an inset edge, and brackets. They are CSS, rather than pixels baked into the PNG, so the card preserves its full 1200 by 630 social-preview dimensions while the article can give it a classical, responsive presentation. The generated manifest stores the chosen shape, color name, and frame for every post. Hugo uses it for both the visible figure and its automatic italic caption.

From draft to deployment

The author-facing workflow is intentionally ordinary:

1. Write Markdown with normal Hugo front matter. No image field, seed, or generator command is required.
2. Stage and commit the post. The generate-post-cards pre-commit hook sees the changed post and runs scripts/stage_post_cards.py.
3. That script invokes scripts/generate_post_cards.py, which rereads all Markdown posts, writes static/images/post-cards/<slug>.png, writes data/post_cards.yaml, and stages both outputs in the same commit.
4. Push the commit. Cloudflare builds Hugo from the committed files, so it needs neither Python nor the scientific rendering stack.
5. Hugo looks up the manifest. It places the card beneath the post metadata, emits the explanatory caption, and adds absolute og:image and twitter:image tags for social crawlers.
6. GitHub Actions installs the pinned matplotlib and numpy versions, regenerates the complete card set, and fails if a committed image or manifest entry differs. The ordinary lint-and-build workflow runs the same hook with those dependencies as well.

The generated assets are committed rather than produced at deploy time. That choice makes every deployed revision self-contained, lets a review inspect the actual pixels, and prevents a future renderer upgrade from changing old cards without a deliberate regeneration commit. The automated caption and manifest make the process inspectable in the finished site, while the hash functions make it reproducible from the source.
